    High Strength Modular Panel Bridge Prefabricated Vehicle Farm Steel Bailey

    Ask Lasest Price
    Brand Name : US-EU Metal
    Model Number : USEU02
    Certification : IS09001
    Price : USD1000-1500 PER TON
    Payment Terms : L/C, T/T
    Supply Ability : 100000 ton per month
    Delivery Time : 20 working days
    • Product Details
    • Company Profile

    High Strength Modular Panel Bridge Prefabricated Vehicle Farm Steel Bailey


    Product Description


    A modular steel bridge is designed to carry the weight of vehicles. Strong and lightweight, these bridges allow you to bridge a road over a stream, railroad, or gulch inexpensively and easily. Modular steel bridges are designed to carry standard highway loads and they can be single or multiple lanes.


    Modular steel bridges can be permanent or temporary. Some municipalities will use a temporary modular steel bridge for a road detour, for example. A modular steel bridge can also be a permanent road bridge for an urban or rural area.


    Bailey Bridges we supply is a modular bridging system that can span up to 67meters. Composed of steel truss panels, these elements are connected together by bolts and pins. The installation completed for panel bridges does not require any specific tools or heavy equipment, and all these elements can be handled manually by a team of 6 workers.


    The bridge is available in a standard width of 3.15m, but also in extra-wide lane (4.20 meters), double lane (7.35 meters) and optional sidewalks. All the components are generally shipped in standard containers.


    Specifications:

    Single laneSTD Carriageway Net Width: 4.2mSingle span: 18m-67m
    Double laneSTD Carriageway Net Width:7.35mSingle span: 18m-67m
    Bridge deckAnti-slip steel decking floor,checkered steel plate etc
    Steel gradeQ345B/Q355 (equivalent to ASTM A572) or custom required
    Loading capacity20ton, 40ton truck etc, or HS20-44, HS25-44/Truck 20/HL-93

    High Strength Modular Panel Bridge Prefabricated Vehicle Farm Steel Bailey 0


    Installation of the Steel Modular Bridge:


    Method 1 Craning: use of certain tons capacity crane on site, which allows a quick and easy assembly and installation


    Method 2 Launching: When the site does not allow crane to work, the Panel Bridge, which can be carried by manpower, can be assembled manually and installed by launching using a pushing device with a limited capacity.


    Advantages:

    Long-term corrosion protection

    High level of mechanical resilience

    Perfect all-round protection also in cavities and edges

    Cathodic corrosion protection

    Attractive appearance

    Very economical

    Maintenance free

    Good Eco-balance, environmentally-friendly process


    Applications:

    Infrastructure upgrading

    Railway

    Highway

    Footbridge

    Emergency

    Military

    Residential community

    Farms

    Rural areas

    Temporary

    Permanent


    FAMOUS runs two well-equipped production bases and the capacity of each one is around 30000-40000tons per year. there are many domestic/overseas projects on the going. In addtion to ISO, we also have the certification of AWS D1.1, AWS D1.5 Bridge field specialized Certification, related tests/inspections have been done .


    High Strength Modular Panel Bridge Prefabricated Vehicle Farm Steel Bailey 1


    Product images:


    High Strength Modular Panel Bridge Prefabricated Vehicle Farm Steel Bailey 2

    High Strength Modular Panel Bridge Prefabricated Vehicle Farm Steel Bailey 3


    High Strength Modular Panel Bridge Prefabricated Vehicle Farm Steel Bailey 4


    If you are interested, please contact us for a quote in whichever means you prefer.
