    Vehicle Prefabricated Steel Truss Pedestrian Bridge Panel Assembled Heavy Haul

    Ask Lasest Price
    Brand Name : Own
    Model Number : CB100, 200, 450 etc
    Certification : ISO9001
    Price : USD1000~USD1800 per ton
    Payment Terms : L/C, T/T, D/A, D/P, Western Union
    Supply Ability : 10000 units per year
    Delivery Time : in 30 days
    • Product Details
    • Company Profile

    Vehicle Prefabricated Steel Truss Pedestrian Bridge Panel Assembled Heavy Haul

    Heavy Haul Vehicular Prefabricated Steel Bailey Truss Panel Assembled Pedestrian Bridge Prefab Construction


    Description of Steel Bailey Bridge


    Steel Bailey bridge is a type of portable, pre-fabricated, truss bridge. It was developed by the British during World War II for military use and saw


    extensive use by British, Canadian and US military engineering units. The bridge has the advantages of few components, light weight and low


    cost. Bailey bridge is similarly like compact 100,compact 200 International bridge. it is assembled by each 3m panel, and invented by Donald


    Bailey. The bridge adopts extensively and the most popular in the world, possessing the features of simple structure, convenient transport,


    speedy erection and easy disassembling.


    Specification of Steel Bailey Bridge


    Product NameSpecification of CB100, 200, 450 type Steel Bailey bridge
    Width4.2m to 7.56m
    Maximum spanup to 81meter single span or 200m multi span
    Bridge deckSteel composit panel
    Steel gradeQ345B (equivalent to ASTM A572)
    Loading capacity20ton, 40ton truck etc up to 120ton payload
    CorrosionOriginal painted or Hot dip galvanized
    AdvantagesPrice effective and technical full analysis and supports

    Our Steel Bailey Bridges are portable steel bridge have been widely used in various fields, its most important feature is to achieve a variety of


    spans, bear carrying capacity, light and handy components, easy to dismantle and strong adaptability can be quickly completed with simple


    tools and manpower.


    Competitive Advantage


    Heavy loading capacity


    Great stability


    Long fatigue life


    Light weight


    Low cost


    Easy and fast erection


    Application


    Our company can do the design, production, fabrication and installation of steel bailey bridge for you according to your requirement, and we


    have much experience in this field. Our steel bailey bridge has a wide range of uses in the following areas:


    · Road Bridges


    · Pedestrian Bridges


    · Railway Bridges


    · Steel Truss Bridge


    · Beam Bridges


    · Steel Bailey bridge


    · Structural Steel Box Bridge


    · Highway Bridges


    · Composite Beam Bridge


    · Cable-Stayed Bridge


    · Floating Bridge etc.


    Features


    Fully galvanized for long life and minimum maintenance


    4.2m single lane


    Durbar finish or factory applied anti-skid surfacing


    Simple, cost effective foundations



    Meanwhile we can also do various standards structural steelworks fabrication ranging from Europe EU Standard, America ASTM Standard, British BS Standard, Australia AS/NZS Standard .


    Warmly welcome all friends and clients from International market to visit us!
